Coffee machine „Ascaso“ Steel DUO PLUS
Add to Cart
Coffee machine „Ascaso“ Steel DUO PLUS
ASCASO Steel Duo PID Plus Coffee Machine
Professional-grade coffee machine for home baristas featuring a double thermoblock system for simultaneous espresso brewing and milk steaming. ASCASO Steel Duo PID Plus ensures optimal workflow, advanced PID temperature control, and consistent extraction.
Technical Specifications
| Model | ASCASO Steel Duo PID Plus |
|---|---|
| Product Type | Professional coffee machine with double thermoblock system |
| Heating System | Double thermoblock system |
| Temperature Control | PID controller with ±1.5°C accuracy |
| Heat-up Time | 1 minute |
| Water Tank Capacity | 2 L (removable side tank) |
| Power Supply | 2000 W |
| Pressure | 15 bar |
| Overall Dimensions | 270 × 315 × 360 mm (W×D×H) |
| Weight | 15 kg |
| Materials | Stainless steel components and accessories |
| Portafilter and Filters | 58 mm diameter, AISI 304 stainless steel |
| Steam Pipes | AISI 316 stainless steel, 360° rotation, heat protection |
| Steam Outlets | 4 tangential holes 1.2 mm (optional 1.6 mm) |
| Hot Water System | AISI 316 stainless steel diffuser |
| Steam Temperature Adjustment | 110°C - 165°C (1°C increments) |
| Programmable Doses | 2 programmable doses |
| Color Variants | Black, White & Stainless Steel |
| Additional Controls | Digital multifunction display, extraction timer, volumetric control, programmable pre-infusion, overpressure valve |
| Lighting | LED barista light for work area and portafilter illumination |
| Design | Modern industrial design |
Key Features and Advantages
• Double thermoblock system for simultaneous espresso brewing and milk steaming
• Advanced PID temperature control with ±1.5°C accuracy
• Fast heat-up - only 1 minute to operating temperature
• Unlimited steam supply from dedicated thermoblock
• 58 mm professional portafilter with ergonomic design
• AISI 316 stainless steel steam pipes with heat protection
• 4 tangential steam outlets for optimal milk cream formation
• Extraction timer for precise process control
• Programmable pre-infusion for optimal extraction
• Overpressure valve for stable pressure
• AISI 304 stainless steel filters with unique serial numbers
• 2L removable side water tank
• LED barista light for portafilter and work area illumination
• Compact modern industrial design
• Quiet and efficient operation
Applications
• Home baristas and coffee enthusiasts
• Professional-grade espresso making at home
• Private homes and apartments
• Small-scale commercial spaces
• Offices and institutions
• Coffee tasting and training spaces
• Any space where efficiency and quality matter
Construction Features
• Double thermoblock system for separate heating and steam generation
• Precise PID temperature control
• High-quality stainless steel construction
• 58 mm diameter ergonomic portafilter with 10° inclination
• AISI 304 stainless steel filters with laser engraved markings
• AISI 316 stainless steel steam pipes with heat protection
• 4 tangential steam outlets for consistent milk steaming
• Hot water diffuser made of AISI 316 stainless steel
• Electromagnetic valve for hot water supply
• Natural wood handles with logo marking
• Removable side water tank for easy maintenance
• Strategically placed LED lighting for work area
• Compact dimensions with optimal functionality
• Intuitive control interface
Operating Parameters and Requirements
• Water: unfiltered or filtered
• Ambient temperature: standard room conditions
• Electrical supply: specifications on request
• Maintenance: regular cleaning and descaling
• Coffee beans: espresso grind size
• Milk: any fat content for steaming
Technological Solutions
• Double thermoblock: separate heating element for espresso brewing and steam/hot water supply
• PID controller: precise temperature maintenance within ±1.5°C range
• Pre-infusion: programmable coffee wetting before extraction
• Overpressure valve: automatic pressure regulation
• Timer: precise extraction process control
Package Contents
• ASCASO Steel Duo PID Plus coffee machine - 1 pc.
• User manual - 1 pc.
• Warranty card - 1 pc.
• Technical documentation - 1 pc.
• Additional accessories as per specification
Warranty and Service
• Official manufacturer warranty
• Professional service network
• Original spare parts
• Technical support and consultations
• Maintenance and repair instructions
Note: Technical specifications are provided based on the official ASCASO brochure (2025). Description prepared based on official ASCASO manufacturer information.
